300 Rolling Window
New Construction
Brickmold Series
Ecoshield’s 300 series new construction rolling windows feature an integrated brickmold trim package, which creates a traditional exterior finish.
The brickmold trim also serves as a J-channel pocket making for a clean finish look and easy installation.
Horizontal views
and maximum daylighting
Rolling windows make the most of a horizontal view while allowing for ventilation through a single or multiple sashes depending on the configuration. Maximize natural light filtration indoors with a rolling window.
Also called sliding windows, the rolling window involves at least two sashes side by side. The sashes can be opened in three configurations, either one is open while the adjacent one is closed, or both sashes can be opened simultaneously.
In a three-sash combination, the center sash remains stationary while the two sashes on either side can be rolled open for ventilation.
Energy Star III and energy star U-4 glazing packages exceed the highest current energy star standards.
Our Energy Star U4 and Energy Star III glazing packages can lower the average home energy bill by 30 to 40 percent, and cut co2 output by 1,600 pounds per year*
Energy Star III
- Energy Star III
Options
- Energy Star U-4
- Clear insulated glass (3/4″)
- Tints, Heat Reflection and other options available
* Courtesy Truseal Technologies
Standard
Options
Standard
Options
Standard
Superior Cam Lock
Kasson & Keller, Inc. Uses high grade alloyed cast steel in our hardware to ensure our windows stand the test of time.
Standard
Options
Multiple Grill Patterns Available
NFRC Thermal Performance Data
| GLAZING | U-VALUE | SHGC | VLT | CR | |
|---|---|---|---|---|---|
| Energy Star U4 | 0.25 | 0.27 | 0.47 | 47 | N,NC |
| Energy Star III | 0.29 | 0.37 | 0.52 | 59 | NC |
| Low E w/ Argon | 0.29 | 0.29 | 0.52 | 59 | NC |
| High Perf. Low E | 0.33 | 0.29 | 0.52 | 56 | |
| Clear Clear-Air-Clear | 0 | 0 | 0 |
NFRC Thermal Performance Data (with Grids)
| GLAZING | U-VALUE | SHGC | VLT | CR | |
|---|---|---|---|---|---|
| Energy Star U4 | - | - | - | - | - |
| Energy Star III | 0.26 | 0.37 | 0.51 | 62 | N,NC |
| Low E w/ Argon | 0.25 | 0.28 | 0.51 | 65 | N,NC |
| High Perf. Low E | 0.30 | 0.28 | 0.51 | 58 | |
| Clear Clear-Air-Clear | 0.46 | 0.61 | 0.63 | 45 |
300 Series – Horizontal Slider (Vinyl Sized)
The table with ID 46 not exists.
Our Windows are made in the Northeast for the Northeast backed by 4 generations of our family – serving you since 1946.
MADE IN AMERICA
Best of Class Warranty
Our Windows are made in the Northeast for the Northeast backed by 4 generations of our family – serving you since 1946.
MADE IN AMERICA
Standard Exterior Colors
Terrastone
Fieldstone
Black
Bronze
Autumn Red
Hunter Green
Have a color in mind? We can custom match it!
*All representations of colors are mechanically reproduced and may vary from the actual product. Terms and conditions apply.
300 Double Hung
New Construction
300 Picture
New Construction
300 Rolling
New Construction
Mill Pond Way
Creative Engineering
Bedford Hills Apartments
Consistent Design
LeBaron County Club
Innovation with Flat Casing
Edinburg Common School
DOE R-5 Energy Efficiency
Whether you are a builder, architect or home owner, Ecoshield new construction windows will offer you a lifetime of worry-free operation, backed by one of the best warranties in the industry.
* Rating, qualification, or compliancy is dependent on selected options and window style.
